Forklift Starters and Alternators - Today's starter motor is usually a permanent-magnet composition or a series-parallel wound direct current electrical motor together with a starter solenoid installed on it. Once current from the starting battery is applied to the solenoid, mainly via a key-operated switch, the solenoid engages a lever that pushes out the drive pinion which is positioned on the driveshaft and meshes the pinion with the starter ring gear which is seen on the engine flywheel.
The solenoid closes the high-current contacts for the starter motor, that begins to turn. Once the engine starts, the key operated switch is opened and a spring inside the solenoid assembly pulls the pinion gear away from the ring gear. This particular action causes the starter motor to stop. The starter's pinion is clutched to its driveshaft by an overrunning clutch. This allows the pinion to transmit drive in just one direction. Drive is transmitted in this method through the pinion to the flywheel ring gear. The pinion remains engaged, like for example because the operator did not release the key as soon as the engine starts or if the solenoid remains engaged for the reason that there is a short. This causes the pinion to spin independently of its driveshaft.
This aforesaid action prevents the engine from driving the starter. This is actually an important step for the reason that this particular type of back drive would enable the starter to spin very fast that it can fly apart. Unless adjustments were made, the sprag clutch arrangement would stop using the starter as a generator if it was utilized in the hybrid scheme discussed earlier. Typically an average starter motor is designed for intermittent utilization that will prevent it being used as a generator.
The electrical parts are made to be able to work for approximately 30 seconds to be able to prevent overheating. Overheating is caused by a slow dissipation of heat is because of ohmic losses. The electrical parts are designed to save weight and cost. This is truly the reason nearly all owner's manuals intended for vehicles recommend the operator to pause for a minimum of 10 seconds after each 10 or 15 seconds of cranking the engine, if trying to start an engine which does not turn over at once.
The overrunning-clutch pinion was launched onto the marked in the early part of the 1960's. Before the 1960's, a Bendix drive was utilized. This drive system works on a helically cut driveshaft that consists of a starter drive pinion placed on it. Once the starter motor begins spinning, the inertia of the drive pinion assembly allows it to ride forward on the helix, hence engaging with the ring gear. As soon as the engine starts, the backdrive caused from the ring gear allows the pinion to surpass the rotating speed of the starter. At this instant, the drive pinion is forced back down the helical shaft and thus out of mesh with the ring gear.
The development of Bendix drive was made during the 1930's with the overrunning-clutch design referred to as the Bendix Folo-Thru drive, developed and launched in the 1960s. The Folo-Thru drive has a latching mechanism along with a set of flyweights in the body of the drive unit. This was better in view of the fact that the typical Bendix drive used to disengage from the ring once the engine fired, though it did not stay running.
As soon as the starter motor is engaged and starts turning, the drive unit is forced forward on the helical shaft by inertia. It then becomes latched into the engaged position. As soon as the drive unit is spun at a speed higher than what is attained by the starter motor itself, like for instance it is backdriven by the running engine, and next the flyweights pull outward in a radial manner. This releases the latch and permits the overdriven drive unit to become spun out of engagement, therefore unwanted starter disengagement can be avoided before a successful engine start.
